Thông tin chi tiết sản phẩm:
Thanh toán:
|
| Tên sản phẩm: | Máy hàn màng địa kỹ thuật CX300 | Độ dày vật liệu hàn: | 0,5mm-1,5mm |
|---|---|---|---|
| Làm nóng nhiệt độ: | 0-450℃ | Trọng lượng tịnh: | 7kg |
| Tốc độ hàn: | 0-8m/phút | Tính thường xuyên: | 50Hz |
| Điện áp: | 220V | Quyền lực: | 1400W |
CX series geomembrane welding machines are equipped with copper or brass hot wedges to ensure efficient and accurate welding process and meet the welding requirements of membranes of different materials. The bearings of the whole machine are imported from Germany, with excellent stability and durability, which effectively extends the service life of the equipment and ensures long-term stable operation.
The welding machines are suitable for welding geomembranes with a thickness of 0.3-4.0mm. They are easy to operate and have excellent performance. They are ideal choices for geomembrane welding projects. The hot air guns are equipped with replaceable different welding nozzles to adapt to different welding needs. It adopts imported heating elements to ensure long-term stable work at high temperature.
The CX300 has a power of 1400W and a weight of 7kg. This is a dual purpose welding machine, supporting the same side into the film, that is, the two films are welded from the left side, the same side into the film unilateral welding, generally used for biogas pond, landfill cover, circular aquaculture pond welding. Normal operation can also accommodate both sides into the film, left and right into the film lap welding.
| Specification | Value |
|---|---|
| Voltage | 220V |
| Frequency | 50HZ |
| Power | 1400W |
| Welding Speed | 0-8m/min |
| Heating Temperature | 0-450℃ |
| Welding Material Thickness | 0.5mm-1.5mm |
| Welding Seam Strength | ≥85% original material |
| Overlap Width | 100mm |
| Net Weight | 7kg |
| Welding Seam Width | 15mm*2, interior cavity material |
The main frame is made of aviation aluminum, die-cast, and painted on the surface, which is light and strong.
The bearing position and screw holes are CNC machined, using Japanese IKO needle roller bearings and German NSK deep groove ball bearings.
The temperature and speed are controlled by computer chip programming, and the LCD screen digitally displays the temperature and speed.
The double handle design is ergonomic and the pressure nut is equipped with a high-strength spring for easy adjustment.
Equipped with a copper hot wedge, the thermal conductivity of copper is 4 times than that of brass. Copper has good viscosity and the fixing screws are not easy to lose.
The wading depth of the machine is 50mm (water less than or equal to 50mm will not burn the machine). The heating cartridge adopts a curved tube design.
